Datasheet	WT505090-10F2-LP-G1 Spec
Standard Package	360
Manufacturer	TDK Corporation
Series	WT
Part Status	Active
Function	Transmitter
Type	1 Coil, 1 Layer
Inductance	6.3µH
Tolerance	-
DC Resistance (DCR)	60mOhm
Q @ Freq	-
Current Rating (Amps)	-
Current - Saturation	-
Frequency - Self Resonant	-
Operating Temperature	-
Size / Dimension	2.02" Dia x 0.13" H (51.4mm x 3.4mm)
