Categories	Inductors, Coils, Chokes / Wireless Charging Coils
Datasheet	WR301025-19M8-G Overview
Standard Package	572
Manufacturer	TDK Corporation
Series	WR
Part Status	Active
Function	Receiver
Type	1 Coil, 2 Layer
Inductance	12.8µH
Tolerance	-
DC Resistance (DCR)	1.27Ohm Max
Q @ Freq	-
Current Rating (Amps)	-
Current - Saturation	-
Frequency - Self Resonant	-
Operating Temperature	-

WT-505060-8K2-LT	TDK Corporation, 1 Coil, 1 Layer 4.95µH Wireless Charging Coil Transmitter 30mOhm, WT	View
WT202012-15F2-ID	TDK Corporation, 1 Coil, 2 Layer 6.2µH Wireless Charging Coil Transmitter 80mOhm, WT	View
WR444030-16F3-G	TDK Corporation, 1 Coil, 1 Layer 19µH Wireless Charging Coil Receiver 700mOhm, WR	View
WR524825-17M6-NF-G	TDK Corporation, 1 Coil, 1 Layer 16.8µH Wireless Charging Coil Receiver 750mOhm, WR	View
WT282890-16F2-G	TDK Corporation, 1 Coil, 2 Layer 7.4µH Wireless Charging Coil Transmitter 110mOhm, WT	View
WR202010-18M8-SM	TDK Corporation, 1 Coil, 2 Layer 10.68µH Wireless Charging Coil Receiver 350mOhm, WR	View
WT505090-10F2-LP-G	TDK Corporation, 1 Coil, 1 Layer 6.3µH Wireless Charging Coil Transmitter 60mOhm, WT	View
WR483265-15F5-G	TDK Corporation, 1 Coil, 1 Layer 13.3µH Wireless Charging Coil Receiver 200mOhm, WR	View
WT505090-10F2-A11-G1	TDK Corporation, 1 Coil, 1 Layer 6.3µH Wireless Charging Coil Transmitter 60mOhm, WT	View
WT545490-11K2-FS	TDK Corporation, 1 Coil, 2 Layer 8.9µH Wireless Charging Coil Transmitter 60mOhm, WT	View
WT-505060-20K2-A10-G	TDK Corporation, 1 Coil, 2 Layer 24µH Wireless Charging Coil Transmitter 100mOhm Max, WT	View
WT505090-20K2-A10-G	TDK Corporation, 1 Coil, 2 Layer 24µH Wireless Charging Coil Transmitter 100mOhm, WT	View

WR301025-19M8-G

Part NumberWR301025-19M8-G
