760308103146


760308103146

Part Number760308103146

Manufacturer

Description

Datasheet

Package / Case

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description

760308103146 - Product Attributes

Categories Inductors, Coils, Chokes / Wireless Charging Coils
Datasheet
Standard Package14
ManufacturerWurth Electronics Inc.
SeriesWE-WPCC
Part StatusActive
FunctionTransmitter
Type1 Coil, 1 Layer
Inductance8.5µH
Tolerance±10%
DC Resistance (DCR)56mOhm Max
Q @ Freq140 @ 125kHz
Current Rating (Amps)8A
Current - Saturation16A
Frequency - Self Resonant11MHz
Operating Temperature-20°C ~ 60°C
Size / Dimension2.01" L x 1.85" W x 0.18" H (51.0mm x 47.0mm x 4.5mm)

760308103146 - Related Products

More >>
760308103215 Wurth Electronics Inc., 1 Coil, 1 Layer 14.3µH Wireless Charging Coil Receiver 190mOhm Max, WE-WPCC View
760308102212 Wurth Electronics Inc., 1 Coil, 1 Layer 5.4µH Wireless Charging Coil Receiver 240mOhm Max, WE-WPCC View
760308103145 Wurth Electronics Inc., 3 Coil, 1 Layer 11.3µH Wireless Charging Coil Receiver, Transmitter 83mOhm Max, WE-WPCC View
760308101141 Wurth Electronics Inc., 1 Coil, 1 Layer 10µH Wireless Charging Coil Transmitter 30mOhm Max, WE-WPCC View
760308103206 Wurth Electronics Inc., 1 Coil, 1 Layer 7.5µH Wireless Charging Coil Receiver 340mOhm, WE-WPCC View
760308102308 Wurth Electronics Inc., 1 Coil, 1 Layer 3µH Wireless Charging Coil Transmitter 35mOhm Max, WE-WPCC View
760308103205 Wurth Electronics Inc., 1 Coil, 1 Layer 11µH Wireless Charging Coil Receiver 180mOhm, WE-WPCC View
760308103146 Wurth Electronics Inc., 1 Coil, 1 Layer 8.5µH Wireless Charging Coil Transmitter 56mOhm Max, WE-WPCC View
760308103147 Wurth Electronics Inc., 3 Coil, 1 Layer 8.5µH, 7.5µH, 8.5µH Wireless Charging Coil Receiver, Transmitter 56mOhm Max, WE-WPCC View
760308103102 Wurth Electronics Inc., 1 Coil, 1 Layer 10µH Wireless Charging Coil Transmitter 55mOhm Max, WE-WPCC View
760308100143 Wurth Electronics Inc., 1 Coil, 1 Layer 6µH Wireless Charging Coil Transmitter 18mOhm Max, WE-WPCC View
760308103307 Wurth Electronics Inc., 2 Coil, 1 Layer 7.8µH, 1.6µH Wireless Charging Coil Receiver 340mOhm Max, 90mOhm Max, WE-WPCC View
