Categories	Discrete Semiconductor Products / Transistors - Bipolar (BJT) - RF
Datasheet	HFA3134,35
Standard Package	3000
Manufacturer	Renesas Electronics America Inc.
Series	-
Packaging	Tape & Reel (TR)
Part Status	Active
Transistor Type	2 NPN (Dual)
Voltage - Collector Emitter Breakdown (Max)	9V
Frequency - Transition	8.5GHz
Noise Figure (dB Typ @ f)	2.4dB @ 1GHz
Gain	-
Power - Max	-
DC Current Gain (hFE) (Min) @ Ic, Vce	48 @ 10mA, 2V
Current - Collector (Ic) (Max)	26mA
Operating Temperature	150°C (TJ)
Mounting Type	Surface Mount
Package / Case	SOT-23-6
Supplier Device Package	SOT-23-6
Base Part Number	HFA3134
