SC-05-D030


SC-05-D030

Part NumberSC-05-D030

Manufacturer

Description

Datasheet

Package / CaseVertical, No Base, 4 PC Pin

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description

SC-05-D030 - Product Attributes

Categories Filters / Common Mode Chokes
Datasheet
Standard Package300
ManufacturerKEMET
SeriesSC
PackagingBulk
Part StatusActive
Filter TypePower Line
Number of Lines2
Inductance @ Frequency30µH @ 100kHz
Current Rating (Max)5A
DC Resistance (DCR) (Max)20mOhm
Voltage Rating - DC250V
Voltage Rating - AC250V
Operating Temperature-25°C ~ 105°C
Ratings-
Approvals-
Features-
Mounting TypeThrough Hole
Size / Dimension0.984" Dia x 0.748" W (25.00mm x 19.00mm)
Height (Max)0.984" (25.00mm)
Package / CaseVertical, No Base, 4 PC Pin
