SC-03-D050

SC-03-D050

Part NumberSC-03-D050

ManufacturerKEMET

DescriptionCOMMON MODE CHOKE 50UH 3A 2LN TH

DatasheetSC-D Series

Package / CaseVertical, No Base, 4 PC Pin

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description50µH @ 100kHz 2 Line Common Mode Choke Through Hole 3A DCR 40mOhm

To learn about the specification of SC-03-D050, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add SC-03-D050 with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of SC-03-D050.
We are offering SC-03-D050 for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

SC-03-D050 - Product Attributes

Categories	Filters / Common Mode Chokes
Datasheet	SC-D Series
Standard Package	360
Manufacturer	KEMET
Series	SC
Packaging	Bulk
Part Status	Active
Filter Type	Power Line
Number of Lines	2
Inductance @ Frequency	50µH @ 100kHz
Current Rating (Max)	3A
DC Resistance (DCR) (Max)	40mOhm
Voltage Rating - DC	250V
Voltage Rating - AC	250V
Operating Temperature	-25°C ~ 105°C
Ratings	-
Approvals	-
Features	-
Mounting Type	Through Hole
Size / Dimension	0.906" Dia x 0.512" W (23.00mm x 13.00mm)
Height (Max)	0.906" (23.00mm)
Package / Case	Vertical, No Base, 4 PC Pin
