B78108E1153K000


B78108E1153K000

Part NumberB78108E1153K000

Manufacturer

Description

Datasheet

Package / CaseAxial

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description

B78108E1153K000 - Product Attributes

Categories Inductors, Coils, Chokes / Fixed Inductors
Datasheet
Standard Package1
ManufacturerEPCOS (TDK)
SeriesBC+
PackagingCut Tape (CT)
Part StatusActive
TypeWirewound
Material - CoreFerrite
Inductance15µH
Tolerance±10%
Current Rating (Amps)1.6A
Current - Saturation1.45A
ShieldingUnshielded
DC Resistance (DCR)230mOhm Max
Q @ Freq40 @ 796kHz
Frequency - Self Resonant15MHz
Ratings-
Operating Temperature-55°C ~ 125°C
Inductance Frequency - Test100kHz
Mounting TypeThrough Hole
Package / CaseAxial
Supplier Device PackageAxial
Size / Dimension0.157" Dia x 0.374" L (4.00mm x 9.50mm)
Height - Seated (Max)-
