DN2470K4-G

DN2470K4-G

Part NumberDN2470K4-G

ManufacturerMicrochip Technology

DescriptionMOSFET N-CH 700V 0.17A 3DPAK

DatasheetDN2470 Datasheet

Package / CaseTO-252-3, DPak (2 Leads + Tab), SC-63

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionN-Channel 700V 170mA (Tj) 2.5W (Ta) Surface Mount TO-252, (D-Pak)

To learn about the specification of DN2470K4-G, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add DN2470K4-G with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of DN2470K4-G.
We are offering DN2470K4-G for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

DN2470K4-G - Product Attributes

Categories	Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Datasheet	DN2470 Datasheet
Standard Package	2000
Manufacturer	Microchip Technology
Series	-
Packaging	Tape & Reel (TR)
Part Status	Active
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	700V
Current - Continuous Drain (Id) @ 25°C	170mA (Tj)
Drive Voltage (Max Rds On, Min Rds On)	0V
Rds On (Max) @ Id, Vgs	42Ohm @ 100mA, 0V
Vgs(th) (Max) @ Id	-
Vgs (Max)	±20V
Input Capacitance (Ciss) (Max) @ Vds	540pF @ 25V
FET Feature	Depletion Mode
Power Dissipation (Max)	2.5W (Ta)
Operating Temperature	-55°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Supplier Device Package	TO-252, (D-Pak)
Package / Case	TO-252-3, DPak (2 Leads + Tab), SC-63
Base Part Number	DN2470
