Categories	Capacitors / Film Capacitors
Datasheet	B32774,76,78 Series
Standard Package	525
Manufacturer	EPCOS (TDK)
Series	B32774
Packaging	Bulk
Part Status	Active
Capacitance	1.5µF
Tolerance	±10%
Voltage Rating - AC	-
Voltage Rating - DC	1300V (1.3kV)
Dielectric Material	Polypropylene (PP), Metallized
ESR (Equivalent Series Resistance)	31.3 mOhms
Operating Temperature	-40°C ~ 105°C
Mounting Type	Through Hole
Package / Case	Radial
Size / Dimension	1.240" L x 0.492" W (31.50mm x 12.50mm)
Height - Seated (Max)	0.846" (21.50mm)
Termination	PC Pins
Lead Spacing	1.083" (27.50mm)
Applications	DC Link, DC Filtering
Ratings	-
Features	Long Life
