Categories	Capacitors / Aluminum Electrolytic Capacitors
Datasheet	ZLG Series
Standard Package	3000
Manufacturer	Rubycon
Series	ZLG
Packaging	Bulk
Part Status	Active
Capacitance	100µF
Tolerance	±20%
Voltage - Rated	10V
ESR (Equivalent Series Resistance)	-
Lifetime @ Temp.	1000 Hrs @ 105°C
Operating Temperature	-40°C ~ 105°C
Polarization	Polar
Ratings	-
Applications	General Purpose
Ripple Current @ Low Frequency	129.6mA @ 120Hz
Ripple Current @ High Frequency	480mA @ 100kHz
Impedance	150 mOhms
Lead Spacing	0.098" (2.50mm)
Size / Dimension	0.248" Dia (6.30mm)
Height - Seated (Max)	0.335" (8.50mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can
