Categories	Capacitors / Ceramic Capacitors
Datasheet	SV Series
Standard Package	200
Manufacturer	AVX Corporation
Series	SV
Packaging	Bulk
Part Status	Active
Capacitance	0.047µF
Tolerance	±10%
Voltage - Rated	2000V (2kV)
Temperature Coefficient	X7R
Operating Temperature	-55°C ~ 125°C
Features	High Voltage
Ratings	-
Applications	General Purpose
Mounting Type	Through Hole
Package / Case	Radial
Size / Dimension	0.571" L x 0.200" W (14.50mm x 5.08mm)
Height - Seated (Max)	0.500" (12.70mm)
Thickness (Max)	-
Lead Spacing	0.476" (12.10mm)
Lead Style	Straight

SV01AC103KAR	AVX Corporation, 10000pF ±10% 1000V (1kV) Ceramic Capacitor X7R Radial, SV	View
SV07AC104KAR	AVX Corporation, 0.1µF ±10% 1000V (1kV) Ceramic Capacitor X7R Radial, SV	View
SV01AC471KAR	AVX Corporation, 470pF ±10% 1000V (1kV) Ceramic Capacitor X7R Radial, SV	View
SV15GC333KAR	AVX Corporation, 0.033µF ±10% 2000V (2kV) Ceramic Capacitor X7R Radial, SV	View
SV17KC273KAR	AVX Corporation, 0.027µF ±10% 5000V (5kV) Ceramic Capacitor X7R Radial, SV	View
SV04GA151KAR	AVX Corporation, 150pF ±10% 2000V (2kV) Ceramic Capacitor C0G, NP0 Radial, SV	View
SV04JA820JAR	AVX Corporation, 82pF ±5% 4000V (4kV) Ceramic Capacitor C0G, NP0 Radial, SV	View
SV13CC222JAR	AVX Corporation, 2200pF ±5% 630V Ceramic Capacitor X7R Radial, SV	View
SV06AC104KAR	AVX Corporation, 0.1µF ±10% 1000V (1kV) Ceramic Capacitor X7R Radial, SV	View
SV06GA222KAR	AVX Corporation, 2200pF ±10% 2000V (2kV) Ceramic Capacitor C0G, NP0 Radial, SV	View
SV13CC224KAR	AVX Corporation, 0.22µF ±10% 630V Ceramic Capacitor X7R Radial, SV	View
SV02AC472KAR	AVX Corporation, 4700pF ±10% 1000V (1kV) Ceramic Capacitor X7R Radial, SV	View

SV07GC473KAR

Part NumberSV07GC473KAR
