Categories	Capacitors / Ceramic Capacitors
Datasheet	SV Series
Standard Package	10
Manufacturer	AVX Corporation
Series	SV
Packaging	Bulk
Part Status	Active
Capacitance	8000pF
Tolerance	±5%
Voltage - Rated	3000V (3kV)
Temperature Coefficient	C0G, NP0
Operating Temperature	-55°C ~ 125°C
Features	High Voltage
Ratings	-
Applications	General Purpose
Mounting Type	Through Hole
Package / Case	Radial
Size / Dimension	0.929" L x 0.250" W (23.60mm x 6.35mm)
Height - Seated (Max)	0.780" (19.80mm)
Thickness (Max)	-
Lead Spacing	0.799" (20.30mm)
Lead Style	Straight

SV08CC105KAR	AVX Corporation, 1µF ±10% 630V Ceramic Capacitor X7R Radial, SV	View
SV13CC101JAR	AVX Corporation, 100pF ±5% 630V Ceramic Capacitor X7R Radial, SV	View
SV13CA103JAR	AVX Corporation, 10000pF ±5% 630V Ceramic Capacitor C0G, NP0 Radial, SV	View
SV09CC185KAR	AVX Corporation, 1.8µF ±10% 630V Ceramic Capacitor X7R Radial, SV	View
SV09AC105KAR	AVX Corporation, 1µF ±10% 1000V (1kV) Ceramic Capacitor X7R Radial, SV	View
SV13GC472KAR	AVX Corporation, 4700pF ±10% 2000V (2kV) Ceramic Capacitor X7R Radial, SV	View
SV15GC333KAR	AVX Corporation, 0.033µF ±10% 2000V (2kV) Ceramic Capacitor X7R Radial, SV	View
SV15JA102JAR	AVX Corporation, 1000pF ±5% 4000V (4kV) Ceramic Capacitor C0G, NP0 Radial, SV	View
SV14GA222JAR	AVX Corporation, 2200pF ±5% 2000V (2kV) Ceramic Capacitor C0G, NP0 Radial, SV	View
SV15KA101JAR	AVX Corporation, 100pF ±5% 5000V (5kV) Ceramic Capacitor C0G, NP0 Radial, SV	View
SV05AC104KAR	AVX Corporation, 0.1µF ±10% 1000V (1kV) Ceramic Capacitor X7R Radial, SV	View
SV09AC474KAR	AVX Corporation, 0.47µF ±10% 1000V (1kV) Ceramic Capacitor X7R Radial, SV	View

SV17HA802JAR

Part NumberSV17HA802JAR
