Categories	Capacitors / Film Capacitors
Datasheet	R76 Series
Standard Package	250
Manufacturer	KEMET
Series	R76
Packaging	Bulk
Part Status	Active
Capacitance	0.1µF
Tolerance	±5%
Voltage Rating - AC	650V
Voltage Rating - DC	1600V (1.6kV)
Dielectric Material	Polypropylene (PP), Metallized
Operating Temperature	-55°C ~ 110°C
Mounting Type	Through Hole
Package / Case	Radial
Size / Dimension	1.043" L x 0.433" W (26.50mm x 11.00mm)
Height - Seated (Max)	0.791" (20.10mm)
Termination	PC Pins
Lead Spacing	0.886" (22.50mm)
Applications	Automotive; High Frequency, Switching; High Pulse, DV/DT
Ratings	AEC-Q200
Features	-

R76TN22204030J	KEMET, 0.022µF Film Capacitor 650V 1600V (1.6kV) Polypropylene (PP), Metallized Radial, R76	View
R76TR3100SE30J	KEMET, 0.1µF Film Capacitor 650V 1600V (1.6kV) Polypropylene (PP), Metallized Radial, R76	View
R76MD2100SE40J	KEMET, 10000pF Film Capacitor 250V 400V Polypropylene (PP), Metallized Radial, R76	View
R76TR31004030J	KEMET, 0.1µF Film Capacitor 650V 1600V (1.6kV) Polypropylene (PP), Metallized Radial, R76	View
R76PD1220SE00J	KEMET, 2200pF Film Capacitor 250V 630V Polypropylene (PP), Metallized Radial, R76	View
R76PW42204030J	KEMET, 2.2µF Film Capacitor 400V 630V Polypropylene (PP), Metallized Radial, R76	View
R76UI1470SE40J	KEMET, 4700pF Film Capacitor 700V 2000V (2kV) Polypropylene (PP), Metallized Radial, R76	View
R76IF2470SE30J	KEMET, 0.047µF Film Capacitor 180V 250V Polypropylene (PP), Metallized Radial, R76	View
R76PI24704030J	KEMET, 0.047µF Film Capacitor 400V 630V Polypropylene (PP), Metallized Radial, R76	View
R76TR32204030J	KEMET, 0.22µF Film Capacitor 650V 1600V (1.6kV) Polypropylene (PP), Metallized Radial, R76	View
R76QF1100SE00J	KEMET, 1000pF Film Capacitor 600V 1000V (1kV) Polypropylene (PP), Metallized Radial, R76	View
R76PD1100SE00J	KEMET, 1000pF Film Capacitor 250V 630V Polypropylene (PP), Metallized Radial, R76	View

R76TN31004040J

Part NumberR76TN31004040J
