NZ2520SHA-80M-END5302A
NZ2520SHA-80M-END5302A
Part Number NZ2520SHA-80M-END5302A Description XTAL OSC XO 80.0000MHZ CMOS SMD Package / Case 1008 (2520 Metric), 4 PC PadUnit Price Request a QuoteLead Time To be ConfirmedDetailed Description 80MHz XO (Standard) CMOS Oscillator 1.8V ~ 3.3V Standby (Power Down) 1008 (2520 Metric), 4 PC Pad
To learn about the specification of NZ2520SHA-80M-END5302A, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add NZ2520SHA-80M-END5302A with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of NZ2520SHA-80M-END5302A.
We are offering NZ2520SHA-80M-END5302A for competitive price in the global market, please send us a quota request for pricing. Thank you!
Payment Methods
Delivery Services
NZ2520SHA-80M-END5302A - Product Attributes
Categories
Crystals, Oscillators, Resonators / Oscillators
Datasheet NZ2520SHA-80M-END5302A Datasheet~ Standard Package 1 Manufacturer NDK America, Inc. Series NZ2520SHA Packaging Cut Tape (CT) Part Status Active Base Resonator Crystal Type XO (Standard) Frequency 80MHz Function Standby (Power Down) Output CMOS Voltage - Supply 1.8V ~ 3.3V Frequency Stability ±100ppm Absolute Pull Range (APR) - Operating Temperature -40°C ~ 125°C Current - Supply (Max) 9mA Ratings AEC-Q100, AEC-Q200 Mounting Type Surface Mount Package / Case 1008 (2520 Metric), 4 PC Pad Size / Dimension 0.098" L x 0.079" W (2.50mm x 2.00mm) Height - Seated (Max) 0.035" (0.90mm) Current - Supply (Disable) (Max) -
