Categories	Discrete Semiconductor Products / Diodes - Bridge Rectifiers
Datasheet	HD01-06
Standard Package	3000
Manufacturer	Diodes Incorporated
Series	-
Packaging	Tape & Reel (TR)
Part Status	Active
Diode Type	Single Phase
Technology	Standard
Voltage - Peak Reverse (Max)	400V
Current - Average Rectified (Io)	800mA
Voltage - Forward (Vf) (Max) @ If	1V @ 400mA
Current - Reverse Leakage @ Vr	5µA @ 400V
Operating Temperature	-55°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Package / Case	4-SMD, Gull Wing
Supplier Device Package	4-MiniDIP
Base Part Number	HD04
