DMP3050LVT-7

DMP3050LVT-7

Part NumberDMP3050LVT-7

ManufacturerDiodes Incorporated

DescriptionMOSFET P CH 30V 4.5A TSOT26

DatasheetDMP3050LVT

Package / CaseSOT-23-6 Thin, TSOT-23-6

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionP-Channel 30V 4.5A (Ta) 1.8W (Ta) Surface Mount TSOT-26

To learn about the specification of DMP3050LVT-7, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add DMP3050LVT-7 with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of DMP3050LVT-7.
We are offering DMP3050LVT-7 for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

DMP3050LVT-7 - Product Attributes

Categories	Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Datasheet	DMP3050LVT
Standard Package	3000
Manufacturer	Diodes Incorporated
Series	-
Packaging	Tape & Reel (TR)
Part Status	Active
FET Type	P-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	30V
Current - Continuous Drain (Id) @ 25°C	4.5A (Ta)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Rds On (Max) @ Id, Vgs	50mOhm @ 4.5A, 10V
Vgs(th) (Max) @ Id	2V @ 250µA
Gate Charge (Qg) (Max) @ Vgs	10.5nC @ 10V
Vgs (Max)	±25V
Input Capacitance (Ciss) (Max) @ Vds	620pF @ 15V
FET Feature	-
Power Dissipation (Max)	1.8W (Ta)
Operating Temperature	-55°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Supplier Device Package	TSOT-26
Package / Case	SOT-23-6 Thin, TSOT-23-6
