Categories	Inductors, Coils, Chokes / Fixed Inductors
Datasheet	CH, CL Series Chokes
Standard Package	1
Manufacturer	Signal Transformer
Series	-
Packaging	Bulk
Part Status	Active
Type	-
Material - Core	-
Inductance	70mH
Tolerance	-
Current Rating (Amps)	2A
Current - Saturation	-
Shielding	Unshielded
DC Resistance (DCR)	900mOhm
Q @ Freq	-
Frequency - Self Resonant	-
Ratings	-
Operating Temperature	-
Mounting Type	Chassis Mount
Package / Case	Nonstandard
Supplier Device Package	-
Size / Dimension	3.374" L x 2.752" W (85.70mm x 69.90mm)
Height - Seated (Max)	2.874" (73.00mm)
