Categories	Capacitors / Film Capacitors
Datasheet	C4AE Series
Standard Package	58
Manufacturer	KEMET
Series	C4AE
Packaging	Bulk
Part Status	Active
Capacitance	20µF
Tolerance	±5%
Voltage Rating - AC	-
Voltage Rating - DC	600V
Dielectric Material	Polypropylene (PP), Metallized
ESR (Equivalent Series Resistance)	5.3 mOhms
Operating Temperature	-40°C ~ 85°C
Mounting Type	Through Hole
Package / Case	Radial - 4 Leads
Size / Dimension	1.634" L x 0.787" W (41.50mm x 20.00mm)
Height - Seated (Max)	1.583" (40.20mm)
Termination	PC Pins
Lead Spacing	1.476" (37.50mm)
Applications	DC Link, DC Filtering; High Frequency, Switching
Ratings	-
Features	-

C4AEQBW5120A3LJ	KEMET, 12µF Film Capacitor 1100V (1.1kV) Polypropylene (PP), Metallized Radial - 4 Leads, C4AE	View
C4AEQBW5270A3NJ	KEMET, 27µF Film Capacitor 1100V (1.1kV) Polypropylene (PP), Metallized Radial, C4AE	View
C4AEJBW5300A3LJ	KEMET, 30µF Film Capacitor 700V Polypropylene (PP), Metallized Radial - 4 Leads, C4AE	View
C4AEOBW5300A3MJ	KEMET, 30µF Film Capacitor 900V Polypropylene (PP), Metallized Radial - 4 Leads, C4AE	View
C4AEOBU4270A1XJ	KEMET, 2.7µF Film Capacitor 900V Polypropylene (PP), Metallized Radial, C4AE	View
C4AEGBW5350A3JJ	KEMET, 35µF Film Capacitor 450V Polypropylene (PP), Metallized Radial - 4 Leads, C4AE	View
C4AEGBW5500A3LJ	KEMET, 50µF Film Capacitor 450V Polypropylene (PP), Metallized Radial - 4 Leads, C4AE	View
C4AEGBU4680A1XJ	KEMET, 6.8µF Film Capacitor 450V Polypropylene (PP), Metallized Radial, C4AE	View
C4AEJBU4400A1XJ	KEMET, 4µF Film Capacitor 700V Polypropylene (PP), Metallized Radial, C4AE	View
C4AEOBU4800A12J	KEMET, 8µF Film Capacitor 900V Polypropylene (PP), Metallized Radial, C4AE	View
C4AEJBW5450A3MJ	KEMET, 45µF Film Capacitor 700V Polypropylene (PP), Metallized Radial - 4 Leads, C4AE	View
C4AEJBU4800A11J	KEMET, 8µF Film Capacitor 700V Polypropylene (PP), Metallized Radial, C4AE	View

C4AEHBW5200A3FJ

Part NumberC4AEHBW5200A3FJ
