Categories	Capacitors / Aluminum Electrolytic Capacitors
Datasheet	QXW Series
Standard Package	500
Manufacturer	Rubycon
Series	QXW
Packaging	Bulk
Part Status	Active
Capacitance	56µF
Tolerance	±20%
Voltage - Rated	450V
ESR (Equivalent Series Resistance)	-
Lifetime @ Temp.	2000 Hrs @ 105°C
Operating Temperature	-40°C ~ 105°C
Polarization	Polar
Ratings	-
Applications	General Purpose
Ripple Current @ Low Frequency	490mA @ 120Hz
Ripple Current @ High Frequency	735mA @ 10kHz
Lead Spacing	0.197" (5.00mm)
Size / Dimension	0.492" Dia (12.50mm)
Height - Seated (Max)	1.457" (37.00mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can

420QXW27MEFR8X45	Rubycon, 27µF 420V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, QXW	View
420QXW22MEFR8X40	Rubycon, 22µF 420V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, QXW	View
450QXW120MEFC18X31.5	Rubycon, 120µF 450V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, QXW	View
450QXW100MEFC16X35	Rubycon, 100µF 450V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, QXW	View
450QXW22MEFR8X45	Rubycon, 22µF 450V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, QXW	View
400QXW22MEFR8X30	Rubycon, 22µF 400V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, QXW	View
450QXW15MEFR8X30	Rubycon, 15µF 450V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, QXW	View
450QXW180MEFC18X45	Rubycon, 180µF 450V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, QXW	View
450QXW18MEFR8X35	Rubycon, 18µF 450V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, QXW	View
450QXW220MEFC18X50	Rubycon, 220µF 450V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, QXW	View
450QXW12MEFR8X25	Rubycon, 12µF 450V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, QXW	View
450QXW68MEFC12.5X40	Rubycon, 68µF 450V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, QXW	View

450QXW56MEFC12.5X35

Part Number450QXW56MEFC12.5X35
