Categories	Capacitors / Aluminum Electrolytic Capacitors
Datasheet	UMV Series
Standard Package	1
Manufacturer	Nichicon
Series	UMV
Packaging	Cut Tape (CT)
Part Status	Active
Capacitance	22µF
Tolerance	±20%
Voltage - Rated	25V
ESR (Equivalent Series Resistance)	-
Lifetime @ Temp.	5000 Hrs @ 105°C
Operating Temperature	-40°C ~ 105°C
Polarization	Polar
Ratings	-
Applications	General Purpose
Ripple Current @ Low Frequency	38mA @ 120Hz
Ripple Current @ High Frequency	57mA @ 10kHz
Lead Spacing	0.098" (2.50mm)
Size / Dimension	0.248" Dia (6.30mm)
Height - Seated (Max)	0.236" (6.00mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can

UMV1E4R7MFD1TP	Nichicon, 4.7µF 25V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV1V220MFD	Nichicon, 22µF 35V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV1C470MFD1TP	Nichicon, 47µF 16V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV1HR47MFD1TP	Nichicon, 0.47µF 50V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV1H100MFD1TP	Nichicon, 10µF 50V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV1E330MFD1TP	Nichicon, 33µF 25V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV1C220MFD	Nichicon, 22µF 16V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV0J101MFD1TP	Nichicon, 100µF 6.3V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV0J470MFD1TP	Nichicon, 47µF 6.3V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV1C100MFD1TP	Nichicon, 10µF 16V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV1HR33MFD1TP	Nichicon, 0.33µF 50V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View
UMV1E330MFD1TP	Nichicon, 33µF 25V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UMV	View

UMV1E220MFD1TP

Part NumberUMV1E220MFD1TP
