TSM085N03PQ33 RGG

TSM085N03PQ33 RGG

Part NumberTSM085N03PQ33 RGG

ManufacturerTaiwan Semiconductor Corporation

DescriptionMOSFET N-CH 30V 52A 8PDFN

DatasheetTSM085N03PQ33

Package / Case8-PowerWDFN

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionN-Channel 30V 52A (Tc) 37W (Tc) Surface Mount 8-PDFN (3x3)

To learn about the specification of TSM085N03PQ33 RGG, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add TSM085N03PQ33 RGG with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of TSM085N03PQ33 RGG.
We are offering TSM085N03PQ33 RGG for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

TSM085N03PQ33 RGG - Product Attributes

Categories	Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Datasheet	TSM085N03PQ33
Standard Package	5000
Manufacturer	Taiwan Semiconductor Corporation
Series	-
Packaging	Tape & Reel (TR)
Part Status	Active
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	30V
Current - Continuous Drain (Id) @ 25°C	52A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Rds On (Max) @ Id, Vgs	8.5mOhm @ 13A, 10V
Vgs(th) (Max) @ Id	2.5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs	14.3nC @ 10V
Vgs (Max)	±20V
Input Capacitance (Ciss) (Max) @ Vds	817pF @ 15V
FET Feature	-
Power Dissipation (Max)	37W (Tc)
Operating Temperature	-55°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Supplier Device Package	8-PDFN (3x3)
Package / Case	8-PowerWDFN
