TFC563D


TFC563D

Part NumberTFC563D

Manufacturer

Description

Datasheet

Package / CaseTO-220-3, Short Tab

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description

TFC563D - Product Attributes

Categories Discrete Semiconductor Products / Thyristors - SCRs
Datasheet
Standard Package50
ManufacturerSanken
Series-
PackagingTube
Part StatusActive
Voltage - Off State600V
Voltage - Gate Trigger (Vgt) (Max)1.5V
Current - Gate Trigger (Igt) (Max)30mA
Voltage - On State (Vtm) (Max)1.4V
Current - Hold (Ih) (Max)12mA
Current - Off State (Max)1mA
Current - Non Rep. Surge 50, 60Hz (Itsm)-
SCR TypeStandard Recovery
Operating Temperature-40°C ~ 125°C
Mounting TypeThrough Hole
Package / CaseTO-220-3, Short Tab
Supplier Device PackageTO-220S
