SRP6540-6R8M


SRP6540-6R8M

Part NumberSRP6540-6R8M

Manufacturer

Description

Datasheet

Package / CaseNonstandard

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description

SRP6540-6R8M - Product Attributes

Categories Inductors, Coils, Chokes / Fixed Inductors
Datasheet
Standard Package1
ManufacturerBourns Inc.
SeriesSRP6540
PackagingCut Tape (CT)
Part StatusActive
TypeWirewound
Material - CoreIron Powder
Inductance6.8µH
Tolerance±20%
Current Rating (Amps)5A
Current - Saturation5.5A
ShieldingShielded
DC Resistance (DCR)49.5mOhm Max
Q @ Freq-
Frequency - Self Resonant-
Ratings-
Operating Temperature-55°C ~ 125°C
Inductance Frequency - Test100kHz
Mounting TypeSurface Mount
Package / CaseNonstandard
Supplier Device Package-
Size / Dimension0.283" L x 0.256" W (7.20mm x 6.50mm)
Height - Seated (Max)0.157" (4.00mm)
Base Part NumberSRP6540
