SRP5020TA-6R8M


SRP5020TA-6R8M

Part NumberSRP5020TA-6R8M

Manufacturer

Description

Datasheet

Package / CaseNonstandard

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description

SRP5020TA-6R8M - Product Attributes

Categories Inductors, Coils, Chokes / Fixed Inductors
Datasheet
Standard Package3000
ManufacturerBourns Inc.
SeriesSRP5020TA
PackagingTape & Reel (TR)
Part StatusActive
TypeWirewound
Material - CoreMetal
Inductance6.8µH
Tolerance±20%
Current Rating (Amps)2.4A
Current - Saturation3.8A
ShieldingShielded
DC Resistance (DCR)150mOhm Max
Q @ Freq20 @ 100kHz
Frequency - Self Resonant23MHz
RatingsAEC-Q200
Operating Temperature-40°C ~ 105°C
Inductance Frequency - Test100kHz
Features-
Mounting TypeSurface Mount
Package / CaseNonstandard
Supplier Device Package-
Size / Dimension0.224" L x 0.205" W (5.70mm x 5.20mm)
Height - Seated (Max)0.079" (2.00mm)
Base Part NumberSRP5020TA
