SRF1260A-680M
SRF1260A-680M
Part Number SRF1260A-680M Description INDUCT ARRAY 2 COIL 68UH SMD Package / Case NonstandardUnit Price Request a QuoteLead Time To be ConfirmedDetailed Description Shielded 2 Coil Inductor Array 272µH Inductance - Connected in Series 68µH Inductance - Connected in Parallel 117mOhm Max DC Resistance (DCR) - Parallel 2.22A Nonstandard
To learn about the specification of SRF1260A-680M, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add SRF1260A-680M with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of SRF1260A-680M.
We are offering SRF1260A-680M for competitive price in the global market, please send us a quota request for pricing. Thank you!
Payment Methods
Delivery Services
SRF1260A-680M - Product Attributes
Categories
Inductors, Coils, Chokes / Arrays, Signal Transformers
Datasheet SRF1260A Series Standard Package 400 Manufacturer Bourns Inc. Series SRF1260A Packaging Tape & Reel (TR) Part Status Active Number of Coils 2 Inductance - Connected In Parallel 68µH Inductance - Connected In Series 272µH Tolerance ±20% Current Rating - Parallel 2.22A Current Rating - Series 1.11A Current Saturation - Parallel 2.7A Current Saturation - Series 1.35A DC Resistance (DCR) - Parallel 117mOhm Max DC Resistance (DCR) - Series 444mOhm Max Shielding Shielded Ratings AEC-Q200 Operating Temperature -40°C ~ 125°C Mounting Type Surface Mount Package / Case Nonstandard Size / Dimension 0.492" L x 0.492" W (12.50mm x 12.50mm) Height 0.244" (6.20mm) Base Part Number SRF1260A
