Categories	Inductors, Coils, Chokes / Fixed Inductors
Datasheet	SCRH2D11 Series
Standard Package	3000
Manufacturer	Signal Transformer
Series	SCRH2D11
Packaging	Tape & Reel (TR)
Part Status	Active
Type	-
Material - Core	-
Inductance	10µH
Tolerance	±30%
Current Rating (Amps)	700mA
Current - Saturation	340mA
Shielding	Shielded
DC Resistance (DCR)	524mOhm Max
Q @ Freq	-
Frequency - Self Resonant	-
Ratings	-
Operating Temperature	-40°C ~ 125°C
Inductance Frequency - Test	100kHz
Mounting Type	Surface Mount
Package / Case	Nonstandard
Supplier Device Package	-
Size / Dimension	0.126" L x 0.126" W (3.20mm x 3.20mm)
Height - Seated (Max)	0.051" (1.30mm)

SC01001518	Skyworks Solutions Inc., 10pF Silicon Capacitor Nonstandard, SC	View
SCIHP1350-3R3M	Signal Transformer, 3.3µH Shielded Wirewound Inductor 14A 9.2mOhm Max Nonstandard, SCIHP1350	View
SCRH127-220	Signal Transformer, 22µH Shielded Inductor 4A 43.2mOhm Max Nonstandard, SCRH127	View
SCIHP0750-4R7	Signal Transformer, 4.7µH Unshielded Wirewound Inductor 6A 37mOhm Max Nonstandard, SCIHP0750	View
302R29W331KV3E-****-SC	Johanson Dielectrics Inc., 330pF ±10% 250V Ceramic Capacitor X7R 1808 (4520 Metric), SC	View
SC00820710	Skyworks Solutions Inc., 8.2pF Silicon Capacitor Nonstandard, SC	View
SCRH104R-220	Signal Transformer, 22µH Shielded Inductor 2.7A 73mOhm Max Nonstandard, SCRH104R	View
SCIH1040HC-R68M	Signal Transformer, 680nH Shielded Wirewound Inductor 22A 2.4mOhm Max Nonstandard, SCIH1040HC	View
SCRH2D11-100	Signal Transformer, 10µH Shielded Inductor 700mA 524mOhm Max Nonstandard, SCRH2D11	View
SC00120912	Skyworks Solutions Inc., 1.2pF Silicon Capacitor 100V Nonstandard Chip, SC	View
SCIH1040HC-R56M	Signal Transformer, 560nH Shielded Wirewound Inductor 25A 1.8mOhm Max Nonstandard, SCIH1040HC	View
SCIHP0530-3R3	Signal Transformer, 3.3µH Shielded Wirewound Inductor 5A Nonstandard, SCIHP0530	View

SCRH2D11-100
