Categories	Resistors / Chip Resistor - Surface Mount
Datasheet	RW Series
Standard Package	10
Manufacturer	Ohmite
Series	RW
Packaging	Bulk
Part Status	Active
Resistance	20 Ohms
Tolerance	±5%
Power (Watts)	5W
Composition	Wirewound
Features	-
Temperature Coefficient	±20ppm/°C
Operating Temperature	-55°C ~ 155°C
Package / Case	SMD, L-Bend
Supplier Device Package	-
Size / Dimension	0.806" L x 0.365" W (20.47mm x 9.27mm)
Height - Seated (Max)	0.406" (10.31mm)
Number of Terminations	2
Failure Rate	-

RW5S0FA10K0JE	Ohmite, 10 kOhms ±5% 5W Chip Resistor SMD, L-Bend Wirewound, RW	View
RW5S0FA4K70JE	Ohmite, 4.7 kOhms ±5% 5W Chip Resistor SMD, L-Bend Wirewound, RW	View
RW5S0FA10R0JE	Ohmite, 10 Ohms ±5% 5W Chip Resistor SMD, L-Bend Wirewound, RW	View
RW5S0FA100RJE	Ohmite, 100 Ohms ±5% 5W Chip Resistor SMD, L-Bend Wirewound, RW	View
RW5S0FAR100FE	Ohmite, 100 mOhms ±1% 5W Chip Resistor SMD, L-Bend Wirewound, RW	View
RW5S0FA1K00JE	Ohmite, 1 kOhms ±5% 5W Chip Resistor SMD, L-Bend Wirewound, RW	View
RW5S0FA20R0JE	Ohmite, 20 Ohms ±5% 5W Chip Resistor SMD, L-Bend Wirewound, RW	View
RW5S0FA1R00FE	Ohmite, 1 Ohms ±1% 5W Chip Resistor SMD, L-Bend Wirewound, RW	View

RW5S0FA20R0JE

Part NumberRW5S0FA20R0JE
