Categories	Capacitors / Aluminum - Polymer Capacitors
Datasheet	RR5 Series
Standard Package	100
Manufacturer	Nichicon
Series	FPCAP, RR5
Packaging	Bulk
Part Status	Active
Type	Polymer
Capacitance	680µF
Tolerance	±20%
Voltage - Rated	6.3V
ESR (Equivalent Series Resistance)	5mOhm
Lifetime @ Temp.	2000 Hrs @ 105°C
Operating Temperature	-55°C ~ 105°C
Ratings	-
Applications	General Purpose
Ripple Current @ Low Frequency	722mA @ 120Hz
Ripple Current @ High Frequency	7.22A @ 100kHz
Lead Spacing	0.197" (5.00mm)
Size / Dimension	0.394" Dia (10.00mm)
Height - Seated (Max)	0.492" (12.50mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can
