PMZB290UNE2YL


PMZB290UNE2YL

Part NumberPMZB290UNE2YL

Manufacturer

Description

Datasheet

Package / Case3-XFDFN

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description

PMZB290UNE2YL - Product Attributes

Categories Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Datasheet
Standard Package1
ManufacturerNexperia USA Inc.
Series-
PackagingCut Tape (CT)
Part StatusActive
FET TypeN-Channel
TechnologyMOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)20V
Current - Continuous Drain (Id) @ 25°C1.2A (Ta)
Drive Voltage (Max Rds On, Min Rds On)1.5V, 4.5V
Rds On (Max) @ Id, Vgs320mOhm @ 1.2A, 4.5V
Vgs(th) (Max) @ Id950mV @ 250µA
Gate Charge (Qg) (Max) @ Vgs1.4nC @ 4.5V
Vgs (Max)±8V
Input Capacitance (Ciss) (Max) @ Vds46pF @ 10V
FET Feature-
Power Dissipation (Max)350mW (Ta), 5.43W (Tc)
Operating Temperature-55°C ~ 150°C (TJ)
Mounting TypeSurface Mount
Supplier Device PackageDFN1006B-3
Package / Case3-XFDFN
