PL8502T


PL8502T

Part NumberPL8502T

Manufacturer

Description

Datasheet

Package / CaseNonstandard

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description

PL8502T - Product Attributes

Categories Inductors, Coils, Chokes / Fixed Inductors
Datasheet
Standard Package300
ManufacturerPulseR
SeriesSLED
PackagingTape & Reel (TR)
Part StatusActive
TypeToroidal
Material - Core-
Inductance25µH
Tolerance±10%
Current Rating (Amps)2.4A
Current - Saturation-
ShieldingUnshielded
DC Resistance (DCR)74mOhm Max
Q @ Freq-
Frequency - Self Resonant-
Ratings-
Operating Temperature-40°C ~ 130°C
Features-
Mounting TypeSurface Mount
Package / CaseNonstandard
Supplier Device Package-
Size / Dimension0.625" L x 0.525" W (15.88mm x 13.34mm)
Height - Seated (Max)0.245" (6.22mm)

PL8502T - Related Products

More >>
PL8502T PulseR, 25µH Unshielded Toroidal Inductor 2.4A 74mOhm Max Nonstandard, SLED View
PL8502T PulseR, 25µH Unshielded Toroidal Inductor 2.4A 74mOhm Max Nonstandard, SLED View
