Categories	Capacitors / Aluminum - Polymer Capacitors
Datasheet	PCV Series Datasheet
Standard Package	1
Manufacturer	Nichicon
Series	PCV
Packaging	Cut Tape (CT)
Part Status	Active
Type	Polymer
Capacitance	8.2µF
Tolerance	±20%
Voltage - Rated	125V
ESR (Equivalent Series Resistance)	84mOhm
Lifetime @ Temp.	3000 Hrs @ 105°C
Operating Temperature	-55°C ~ 105°C
Ratings	-
Applications	General Purpose
Ripple Current @ High Frequency	1.3A @ 100kHz
Lead Spacing	-
Size / Dimension	0.315" Dia (8.00mm)
Height - Seated (Max)	0.476" (12.10mm)
Surface Mount Land Size	0.327" L x 0.327" W (8.30mm x 8.30mm)
Mounting Type	Surface Mount
Package / Case	Radial, Can - SMD

PCV1E271MCL2GS	Nichicon, 270µF 25V Aluminum Polymer Capacitor Radial, Can - SMD 23mOhm 3000 Hrs @ 105°C, PCV	View
PCV1E391MCL2GS	Nichicon, 390µF 25V Aluminum Polymer Capacitor Radial, Can - SMD 21mOhm 3000 Hrs @ 105°C, PCV	View
PCV1C221MCL1GS	Nichicon, 220µF 16V Aluminum Polymer Capacitor Radial, Can - SMD 31mOhm 3000 Hrs @ 105°C, PCV	View
PCV2B120MCL1GS	Nichicon, 12µF 125V Aluminum Polymer Capacitor Radial, Can - SMD 69mOhm 3000 Hrs @ 105°C, PCV	View
PCV1J270MCL1GS	Nichicon, 27µF 63V Aluminum Polymer Capacitor Radial, Can - SMD 35mOhm 3000 Hrs @ 105°C, PCV	View
PCV1D101MCL2GS	Nichicon, 100µF 20V Aluminum Polymer Capacitor Radial, Can - SMD 42mOhm 3000 Hrs @ 105°C, PCV	View
PCV1C271MCL7GS	Nichicon, 270µF 16V Aluminum Polymer Capacitor Radial, Can - SMD 21mOhm 3000 Hrs @ 105°C, PCV	View
PCV1J8R2MCL2GS	Nichicon, 8.2µF 63V Aluminum Polymer Capacitor Radial, Can - SMD 56mOhm 3000 Hrs @ 105°C, PCV	View
PCV1K150MCL1GS	Nichicon, 15µF 80V Aluminum Polymer Capacitor Radial, Can - SMD 39mOhm 3000 Hrs @ 105°C, PCV	View
PCV1K120MCL1GS	Nichicon, 12µF 80V Aluminum Polymer Capacitor Radial, Can - SMD 41mOhm 3000 Hrs @ 105°C, PCV	View
PCV1J5R6MCL1GS	Nichicon, 5.6µF 63V Aluminum Polymer Capacitor Radial, Can - SMD 105mOhm 3000 Hrs @ 105°C, PCV	View
PCV1K220MCL1GS	Nichicon, 22µF 80V Aluminum Polymer Capacitor Radial, Can - SMD 38mOhm 3000 Hrs @ 105°C, PCV	View

PCV2B8R2MCL1GS

Part NumberPCV2B8R2MCL1GS
