Categories	Capacitors / Film Capacitors
Datasheet	WIMA MKP 10
Standard Package	126
Manufacturer	WIMA
Series	-
Packaging	Bulk
Part Status	Active
Capacitance	3.3µF
Tolerance	±20%
Voltage Rating - AC	250V
Voltage Rating - DC	400V
Dielectric Material	Polypropylene (PP), Metallized
Operating Temperature	-55°C ~ 100°C
Mounting Type	Through Hole
Package / Case	Radial
Size / Dimension	1.634" L x 0.787" W (41.50mm x 20.00mm)
Height - Seated (Max)	1.555" (39.50mm)
Termination	PC Pins
Lead Spacing	1.476" (37.50mm)
Applications	High Pulse, DV/DT
Ratings	-
Features	-
