KSA1220AYS

KSA1220AYS

Part NumberKSA1220AYS

ManufacturerON Semiconductor

DescriptionTRANS PNP 160V 1.2A TO-126

DatasheetKSA1220/1220A

Package / CaseTO-225AA, TO-126-3

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionBipolar (BJT) Transistor PNP 160V 1.2A 175MHz 1.2W Through Hole TO-126

To learn about the specification of KSA1220AYS, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add KSA1220AYS with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of KSA1220AYS.
We are offering KSA1220AYS for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

KSA1220AYS - Product Attributes

Categories	Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Datasheet	KSA1220/1220A
Standard Package	2000
Manufacturer	ON Semiconductor
Series	-
Packaging	Bulk
Part Status	Active
Transistor Type	PNP
Current - Collector (Ic) (Max)	1.2A
Voltage - Collector Emitter Breakdown (Max)	160V
Vce Saturation (Max) @ Ib, Ic	700mV @ 200mA, 1A
Current - Collector Cutoff (Max)	1µA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce	160 @ 300mA, 5V
Power - Max	1.2W
Frequency - Transition	175MHz
Operating Temperature	150°C (TJ)
Mounting Type	Through Hole
Package / Case	TO-225AA, TO-126-3
Supplier Device Package	TO-126
Base Part Number	KSA1220
