JANTX1N4248

JANTX1N4248

Part NumberJANTX1N4248

ManufacturerMicrosemi Corporation

DescriptionDIODE GEN PURP 800V 1A E3

Datasheet1N4245-49

Package / CaseE3

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionDiode Standard 800V 1A E3

To learn about the specification of JANTX1N4248, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add JANTX1N4248 with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of JANTX1N4248.
We are offering JANTX1N4248 for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

JANTX1N4248 - Product Attributes

Categories	Discrete Semiconductor Products / Diodes - Rectifiers - Single
Datasheet	1N4245-49
Standard Package	1
Manufacturer	Microsemi Corporation
Series	Military, MIL-PRF-19500/286
Packaging	Bulk
Part Status	Active
Diode Type	Standard
Voltage - DC Reverse (Vr) (Max)	800V
Current - Average Rectified (Io)	1A
Voltage - Forward (Vf) (Max) @ If	1.3V @ 3A
Speed	Standard Recovery >500ns, > 200mA (Io)
Reverse Recovery Time (trr)	5µs
Current - Reverse Leakage @ Vr	1µA @ 800V
Capacitance @ Vr, F	-
Package / Case	E3
Supplier Device Package	E3
Operating Temperature - Junction	-65°C ~ 175°C
