IXFN55N50F

IXFN55N50F

Part NumberIXFN55N50F

ManufacturerIXYS-RF

DescriptionMOSFET N-CH 500V 55A SOT227B

DatasheetIXFN55N50F

Package / CaseSOT-227-4, miniBLOC

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionN-Channel 500V 55A (Tc) 600W (Tc) Chassis Mount SOT-227B

To learn about the specification of IXFN55N50F, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add IXFN55N50F with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of IXFN55N50F.
We are offering IXFN55N50F for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

IXFN55N50F - Product Attributes

Categories	Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Datasheet	IXFN55N50F
Standard Package	10
Manufacturer	IXYS-RF
Series	HiPerRF™
Packaging	Tube
Part Status	Active
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	500V
Current - Continuous Drain (Id) @ 25°C	55A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	10V
Rds On (Max) @ Id, Vgs	85mOhm @ 27.5A, 10V
Vgs(th) (Max) @ Id	5.5V @ 8mA
Gate Charge (Qg) (Max) @ Vgs	195nC @ 10V
Vgs (Max)	±20V
Input Capacitance (Ciss) (Max) @ Vds	6700pF @ 25V
FET Feature	-
Power Dissipation (Max)	600W (Tc)
Operating Temperature	-55°C ~ 150°C (TJ)
Mounting Type	Chassis Mount
Supplier Device Package	SOT-227B
Package / Case	SOT-227-4, miniBLOC
