IXFJ20N85X

IXFJ20N85X

Part NumberIXFJ20N85X

ManufacturerIXYS

DescriptionMOSFET N-CH 850V 9.5A TO247

DatasheetIXFJ20N85X

Package / CaseTO-247-3

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionN-Channel 850V 9.5A (Tc) 110W (Tc) Through Hole ISO TO-247-3

To learn about the specification of IXFJ20N85X, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add IXFJ20N85X with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of IXFJ20N85X.
We are offering IXFJ20N85X for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

IXFJ20N85X - Product Attributes

Categories	Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Datasheet	IXFJ20N85X
Standard Package	30
Manufacturer	IXYS
Series	HiPerFET™
Packaging	Tube
Part Status	Active
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	850V
Current - Continuous Drain (Id) @ 25°C	9.5A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	10V
Rds On (Max) @ Id, Vgs	360mOhm @ 10A, 10V
Vgs(th) (Max) @ Id	5.5V @ 2.5mA
Gate Charge (Qg) (Max) @ Vgs	63nC @ 10V
Vgs (Max)	±30V
Input Capacitance (Ciss) (Max) @ Vds	1660pF @ 25V
FET Feature	-
Power Dissipation (Max)	110W (Tc)
Operating Temperature	-55°C ~ 150°C (TJ)
Mounting Type	Through Hole
Supplier Device Package	ISO TO-247-3
Package / Case	TO-247-3
