IRF6617TRPBF

IRF6617TRPBF

Part NumberIRF6617TRPBF

ManufacturerInfineon Technologies

DescriptionMOSFET N-CH 30V 14A DIRECTFET

DatasheetIRF6617(TR)PbF

Package / CaseDirectFET™ Isometric ST

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionN-Channel 30V 14A (Ta), 55A (Tc) 2.1W (Ta), 42W (Tc) Surface Mount DIRECTFET™ ST

To learn about the specification of IRF6617TRPBF, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add IRF6617TRPBF with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of IRF6617TRPBF.
We are offering IRF6617TRPBF for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

IRF6617TRPBF - Product Attributes

Categories	Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Datasheet	IRF6617(TR)PbF
Standard Package	1
Manufacturer	Infineon Technologies
Series	HEXFET®
Packaging	Cut Tape (CT)
Part Status	Active
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	30V
Current - Continuous Drain (Id) @ 25°C	14A (Ta), 55A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Rds On (Max) @ Id, Vgs	8.1mOhm @ 15A, 10V
Vgs(th) (Max) @ Id	2.35V @ 250µA
Gate Charge (Qg) (Max) @ Vgs	17nC @ 4.5V
Vgs (Max)	±20V
Input Capacitance (Ciss) (Max) @ Vds	1300pF @ 15V
FET Feature	-
Power Dissipation (Max)	2.1W (Ta), 42W (Tc)
Operating Temperature	-40°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Supplier Device Package	DIRECTFET™ ST
Package / Case	DirectFET™ Isometric ST
