BSS138PW,115

BSS138PW,115

Part NumberBSS138PW,115

ManufacturerNexperia USA Inc.

DescriptionMOSFET N-CH 60V 320MA SOT323

DatasheetBSS138PW Datasheet

Package / CaseSC-70, SOT-323

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionN-Channel 60V 320mA (Ta) 260mW (Ta), 830mW (Tc) Surface Mount SC-70

To learn about the specification of BSS138PW,115, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add BSS138PW,115 with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of BSS138PW,115.
We are offering BSS138PW,115 for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

BSS138PW,115 - Product Attributes

Categories	Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Datasheet	BSS138PW Datasheet
Standard Package	3000
Manufacturer	Nexperia USA Inc.
Series	Automotive, AEC-Q101, TrenchMOS™
Packaging	Tape & Reel (TR)
Part Status	Active
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	60V
Current - Continuous Drain (Id) @ 25°C	320mA (Ta)
Drive Voltage (Max Rds On, Min Rds On)	10V
Rds On (Max) @ Id, Vgs	1.6Ohm @ 300mA, 10V
Vgs(th) (Max) @ Id	1.5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs	0.8nC @ 4.5V
Vgs (Max)	±20V
Input Capacitance (Ciss) (Max) @ Vds	50pF @ 10V
FET Feature	-
Power Dissipation (Max)	260mW (Ta), 830mW (Tc)
Operating Temperature	-55°C ~ 150°C (TA)
Mounting Type	Surface Mount
Supplier Device Package	SC-70
Package / Case	SC-70, SOT-323
