Categories	Capacitors / Ceramic Capacitors
Datasheet	564R, 565R Series Datasheet
Standard Package	250
Manufacturer	Vishay Cera-Mite
Series	Cera-Mite 564R
Packaging	Bulk
Part Status	Active
Capacitance	10pF
Tolerance	±20%
Voltage - Rated	6000V (6kV)
Temperature Coefficient	C0G, NP0
Operating Temperature	-25°C ~ 105°C
Features	-
Ratings	-
Applications	General Purpose
Failure Rate	-
Mounting Type	Through Hole
Package / Case	Radial, Disc
Size / Dimension	0.402" Dia (10.20mm)
Height - Seated (Max)	0.591" (15.00mm)
Thickness (Max)	-
Lead Spacing	0.374" (9.50mm)
Lead Style	Straight

564R30GAT33	Vishay Cera-Mite, 330pF ±20% 3000V (3kV) Ceramic Capacitor X5R Radial, Disc, Cera-Mite 564R	View
564R60GAQ10	Vishay Cera-Mite, 10pF ±20% 6000V (6kV) Ceramic Capacitor C0G, NP0 Radial, Disc, Cera-Mite 564R	View
564R30GASS10	Vishay Cera-Mite, 10000pF ±20% 3000V (3kV) Ceramic Capacitor Y5V (F) Radial, Disc, Cera-Mite 564R	View
564R30GAT27	Vishay Cera-Mite, 270pF ±20% 3000V (3kV) Ceramic Capacitor X5F Radial, Disc, Cera-Mite 564R	View
564R30GAT10	Vishay Cera-Mite, 100pF ±20% 3000V (3kV) Ceramic Capacitor X7R Radial, Disc, Cera-Mite 564R	View
564R30GAT22	Vishay Cera-Mite, 220pF ±20% 3000V (3kV) Ceramic Capacitor X7R Radial, Disc, Cera-Mite 564R	View
564R30TSD33	Vishay Cera-Mite, 3300pF ±10% 3000V (3kV) Ceramic Capacitor X7R Radial, Disc, Cera-Mite 564R	View
564R30GAT47	Vishay Cera-Mite, 470pF ±20% 3000V (3kV) Ceramic Capacitor X5S Radial, Disc, Cera-Mite 564R	View
564R30GAD33	Vishay Cera-Mite, 3300pF ±20% 3000V (3kV) Ceramic Capacitor Z5U Radial, Disc, Cera-Mite 564R	View
564R60GAD10	Vishay Cera-Mite, 1000pF ±20% 6000V (6kV) Ceramic Capacitor Z5U Radial, Disc, Cera-Mite 564R	View
564R30GAQ47	Vishay Cera-Mite, 47pF ±20% 3000V (3kV) Ceramic Capacitor X7R Radial, Disc, Cera-Mite 564R	View
564R30TSD10	Vishay Cera-Mite, 1000pF ±20% 3000V (3kV) Ceramic Capacitor X7R Radial, Disc, Cera-Mite 564R	View

564R60GAQ10

Part Number564R60GAQ10
