Categories	Capacitors / Aluminum Electrolytic Capacitors
Datasheet	BXC Series
Standard Package	600
Manufacturer	Rubycon
Series	BXC
Packaging	Bulk
Part Status	Active
Capacitance	22µF
Tolerance	±20%
Voltage - Rated	450V
ESR (Equivalent Series Resistance)	-
Lifetime @ Temp.	12000 Hrs @ 105°C
Operating Temperature	-25°C ~ 105°C
Polarization	Polar
Ratings	-
Applications	General Purpose
Ripple Current @ Low Frequency	304mA @ 120Hz
Ripple Current @ High Frequency	760mA @ 100kHz
Lead Spacing	0.295" (7.50mm)
Size / Dimension	0.630" Dia (16.00mm)
Height - Seated (Max)	0.866" (22.00mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can

250BXC22MEFC10X20	Rubycon, 22µF 250V Aluminum Electrolytic Capacitors Radial, Can 10000 Hrs @ 105°C, BXC	View
450BXC10MEFCG412.5X20	Rubycon, 10µF 450V Aluminum Electrolytic Capacitors Radial, Can 12000 Hrs @ 105°C, BXC	View
250BXC4.7MEFC8X11.5	Rubycon, 4.7µF 250V Aluminum Electrolytic Capacitors Radial, Can 8000 Hrs @ 105°C, BXC	View
400BXC2.2MEFC8X11.5	Rubycon, 2.2µF 400V Aluminum Electrolytic Capacitors Radial, Can 8000 Hrs @ 105°C, BXC	View
250BXC100MEFC16X25	Rubycon, 100µF 250V Aluminum Electrolytic Capacitors Radial, Can 12000 Hrs @ 105°C, BXC	View
450BXC10MEFCG412.5X20	Rubycon, 10µF 450V Aluminum Electrolytic Capacitors Radial, Can 12000 Hrs @ 105°C, BXC	View
250BXC68MEFC16X20	Rubycon, 68µF 250V Aluminum Electrolytic Capacitors Radial, Can 12000 Hrs @ 105°C, BXC	View
250BXC22MEFCT810X16	Rubycon, 22µF 250V Aluminum Electrolytic Capacitors Radial, Can 10000 Hrs @ 105°C, BXC	View
400BXC1MEFCT810X12.5	Rubycon, 1µF 400V Aluminum Electrolytic Capacitors Radial, Can 8000 Hrs @ 105°C, BXC	View
450BXC4.7MEFC10X16	Rubycon, 4.7µF 450V Aluminum Electrolytic Capacitors Radial, Can 10000 Hrs @ 105°C, BXC	View
350BXC22MEFC12.5X20	Rubycon, 22µF 350V Aluminum Electrolytic Capacitors Radial, Can 12000 Hrs @ 105°C, BXC	View
500BXC10MEFC12.5X20	Rubycon, 10µF 500V Aluminum Electrolytic Capacitors Radial, Can 12000 Hrs @ 105°C, BXC	View

450BXC22MEFC16X20

Part Number450BXC22MEFC16X20
