Categories	Capacitors / Aluminum Electrolytic Capacitors
Datasheet	CFX Series
Standard Package	500
Manufacturer	Rubycon
Series	CFX
Packaging	Tape & Box (TB)
Part Status	Active
Capacitance	22µF
Tolerance	±20%
Voltage - Rated	400V
ESR (Equivalent Series Resistance)	-
Lifetime @ Temp.	5000 Hrs @ 105°C
Operating Temperature	-25°C ~ 105°C
Polarization	Polar
Ratings	-
Applications	General Purpose
Ripple Current @ Low Frequency	215mA @ 120Hz
Ripple Current @ High Frequency	430mA @ 100kHz
Lead Spacing	0.197" (5.00mm)
Size / Dimension	0.492" Dia (12.50mm)
Height - Seated (Max)	1.063" (27.00mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can

200CFX22MEFC10X16	Rubycon, 22µF 200V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, CFX	View
250CFX22MEFC10X20	Rubycon, 22µF 250V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, CFX	View
250CFX10MEFC10X16	Rubycon, 10µF 250V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, CFX	View
400CFX4.7MEFC10X16	Rubycon, 4.7µF 400V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, CFX	View
400CFX6.8MEFC10X16	Rubycon, 6.8µF 400V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, CFX	View
400CFX22MEFCG412.5X25	Rubycon, 22µF 400V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, CFX	View
400CFX22MEFCG412.5X25	Rubycon, 22µF 400V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, CFX	View
250CFX68MEFC16X25	Rubycon, 68µF 250V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, CFX	View

400CFX22MEFCG412.5X25

Part Number400CFX22MEFCG412.5X25
