Categories	Capacitors / Tantalum Capacitors
Datasheet	109D
Standard Package	1
Manufacturer	Vishay Sprague
Series	TANTALEX®, 109D
Packaging	Tray
Part Status	Active
Capacitance	100µF
Tolerance	±10%
Voltage - Rated	60V
Type	Hermetically Sealed
ESR (Equivalent Series Resistance)	2.5Ohm
Operating Temperature	-55°C ~ 125°C
Lifetime @ Temp.	-
Mounting Type	Through Hole
Package / Case	Axial
Size / Dimension	0.312" Dia x 0.796" L (7.92mm x 20.22mm)
Height - Seated (Max)	-
Lead Spacing	-
Manufacturer Size Code	F
Features	Wet Tantalum
Failure Rate	-

109D567X9025T2	Vishay Sprague, 560µF Hermetically Sealed Tantalum Capacitors 25V Axial 1.8Ohm, TANTALEX®, 109D	View
109D277X9025F2	Vishay Sprague, 270µF Hermetically Sealed Tantalum Capacitors 25V Axial 2.7Ohm, TANTALEX®, 109D	View
109D107X9060F2	Vishay Sprague, 100µF Hermetically Sealed Tantalum Capacitors 60V Axial 2.5Ohm, TANTALEX®, 109D	View
109D566X9075T2	Vishay Sprague, 56µF Hermetically Sealed Tantalum Capacitors 75V Axial 6Ohm, TANTALEX®, 109D	View
109D187X9075T2	Vishay Sprague, 180µF Hermetically Sealed Tantalum Capacitors 75V Axial 1.8Ohm, TANTALEX®, 109D	View
109D336X9050C2	Vishay Sprague, 33µF Hermetically Sealed Tantalum Capacitors 50V Axial 5Ohm, TANTALEX®, 109D	View
109D476X9050F2	Vishay Sprague, 47µF Hermetically Sealed Tantalum Capacitors 50V Axial 6Ohm, TANTALEX®, 109D	View
109D277X9050T2	Vishay Sprague, 270µF Hermetically Sealed Tantalum Capacitors 50V Axial 1.8Ohm, TANTALEX®, 109D	View
109D826X9075F2	Vishay Sprague, 82µF Hermetically Sealed Tantalum Capacitors 75V Axial 2.5Ohm, TANTALEX®, 109D	View
109D226X9075C2	Vishay Sprague, 22µF Hermetically Sealed Tantalum Capacitors 75V Axial 5Ohm, TANTALEX®, 109D	View
109D127X9050F2	Vishay Sprague, 120µF Hermetically Sealed Tantalum Capacitors 50V Axial 2.5Ohm, TANTALEX®, 109D	View

109D107X9060F2

Part Number109D107X9060F2
