Categories	Resistors / Through Hole Resistors
Datasheet	WH, WN Series
Standard Package	1000
Manufacturer	Ohmite
Series	WH
Packaging	Tape & Reel (TR)
Part Status	Active
Resistance	200 Ohms
Tolerance	±1%
Power (Watts)	2W
Composition	Wirewound
Features	-
Temperature Coefficient	±20ppm/°C
Operating Temperature	-55°C ~ 150°C
Package / Case	Axial
Supplier Device Package	Axial
Size / Dimension	0.180" Dia x 0.449" L (4.57mm x 11.40mm)
Height - Seated (Max)	-
Number of Terminations	2
Failure Rate	-

WHBR10FET	Ohmite, 100 mOhms ±1% 1W Through Hole Resistor Axial Wirewound, WH	View
WHC560FET	Ohmite, 560 Ohms ±1% 2W Through Hole Resistor Axial Wirewound, WH	View
WHA1R0FET	Ohmite, 1 Ohms ±1% 0.5W, 1/2W Through Hole Resistor Axial Wirewound, WH	View
WHB200FET	Ohmite, 200 Ohms ±1% 1W Through Hole Resistor Axial Wirewound, WH	View
WHD5K0FET	Ohmite, 5 kOhms ±1% 3W Through Hole Resistor Axial Wirewound, WH	View
WHA15RFET	Ohmite, 15 Ohms ±1% 0.5W, 1/2W Through Hole Resistor Axial Wirewound, WH	View
WHAR25FET	Ohmite, 250 mOhms ±1% 0.5W, 1/2W Through Hole Resistor Axial Wirewound, WH	View
WHAR10FET	Ohmite, 100 mOhms ±1% 0.5W, 1/2W Through Hole Resistor Axial Wirewound, WH	View
WHA5R0FET	Ohmite, 5 Ohms ±1% 0.5W, 1/2W Through Hole Resistor Axial Wirewound, WH	View
WHA250FET	Ohmite, 250 Ohms ±1% 0.5W, 1/2W Through Hole Resistor Axial Wirewound, WH	View
WHA100FET	Ohmite, 100 Ohms ±1% 0.5W, 1/2W Through Hole Resistor Axial Wirewound, WH	View
WHC10RFET	Ohmite, 10 Ohms ±1% 2W Through Hole Resistor Axial Wirewound, WH	View

WHC200FET

Part NumberWHC200FET
