Categories	Capacitors / Aluminum Electrolytic Capacitors
Datasheet	UVZ Series
Standard Package	1
Manufacturer	Nichicon
Series	UVZ
Packaging	Cut Tape (CT)
Part Status	Active
Capacitance	22µF
Tolerance	±20%
Voltage - Rated	400V
ESR (Equivalent Series Resistance)	-
Lifetime @ Temp.	1000 Hrs @ 105°C
Operating Temperature	-40°C ~ 105°C
Polarization	Polar
Ratings	-
Applications	General Purpose
Ripple Current @ Low Frequency	165mA @ 120Hz
Ripple Current @ High Frequency	264mA @ 10kHz
Lead Spacing	0.295" (7.50mm)
Size / Dimension	0.630" Dia (16.00mm)
Height - Seated (Max)	1.063" (27.00mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can

UVZ2E470MHD	Nichicon, 47µF 250V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVZ	View
UVZ2V4R7MPD1TD	Nichicon, 4.7µF 350V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVZ	View
UVZ1A102MPD1TD	Nichicon, 1000µF 10V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVZ	View
UVZ1A153MHD	Nichicon, 15000µF 10V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVZ	View
UVZ2C471MRD	Nichicon, 470µF 160V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVZ	View
UVZ1H220MDD1TD	Nichicon, 22µF 50V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVZ	View
UVZ1C470MDD1TD	Nichicon, 47µF 16V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVZ	View
UVZ2E010MED1TD	Nichicon, 1µF 250V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVZ	View
UVZ2E010MED1TD	Nichicon, 1µF 250V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVZ	View
UVZ0J331MED1TD	Nichicon, 330µF 6.3V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVZ	View
UVZ1J102MHD1TN	Nichicon, 1000µF 63V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVZ	View
UVZ2F3R3MPD1TD	Nichicon, 3.3µF 315V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVZ	View

UVZ2G220MHD1TN

Part NumberUVZ2G220MHD1TN
