Categories	Capacitors / Aluminum Electrolytic Capacitors
Datasheet	UVZ Series
Standard Package	1
Manufacturer	Nichicon
Series	UVZ
Packaging	Cut Tape (CT)
Part Status	Active
Capacitance	47µF
Tolerance	±20%
Voltage - Rated	250V
ESR (Equivalent Series Resistance)	-
Lifetime @ Temp.	1000 Hrs @ 105°C
Operating Temperature	-40°C ~ 105°C
Polarization	Polar
Ratings	-
Applications	General Purpose
Ripple Current @ Low Frequency	210mA @ 120Hz
Ripple Current @ High Frequency	336mA @ 10kHz
Lead Spacing	0.197" (5.00mm)
Size / Dimension	0.492" Dia (12.50mm)
Height - Seated (Max)	1.063" (27.00mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can

UVZ1H331MPD	Nichicon, 330µF 50V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVZ	View
UVZ2F4R7MPD1TD	Nichicon, 4.7µF 315V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVZ	View
UVZ0J103MHD1TN	Nichicon, 10000µF 6.3V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVZ	View
UVZ2C3R3MED1TD	Nichicon, 3.3µF 160V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVZ	View
UVZ2G3R3MPD1TD	Nichicon, 3.3µF 400V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVZ	View
UVZ1A472MHD1TO	Nichicon, 4700µF 10V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVZ	View
UVZ1A333MRD	Nichicon, 33000µF 10V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVZ	View
UVZ1J471MHD1TO	Nichicon, 470µF 63V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVZ	View
UVZ2W010MPD1TD	Nichicon, 1µF 450V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVZ	View
UVZ2AR47MDD1TD	Nichicon, 0.47µF 100V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVZ	View
UVZ1H471MHD	Nichicon, 470µF 50V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVZ	View
UVZ2D220MPD1TD	Nichicon, 22µF 200V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVZ	View

UVZ2E470MHD1TO

Part NumberUVZ2E470MHD1TO
