Categories	Capacitors / Aluminum Electrolytic Capacitors
Datasheet	UVY Series
Standard Package	1
Manufacturer	Nichicon
Series	UVY
Packaging	Cut Tape (CT)
Part Status	Not For New Designs
Capacitance	0.1µF
Tolerance	±20%
Voltage - Rated	200V
ESR (Equivalent Series Resistance)	-
Lifetime @ Temp.	1000 Hrs @ 105°C
Operating Temperature	-40°C ~ 105°C
Polarization	Polar
Ratings	-
Applications	General Purpose
Ripple Current @ Low Frequency	1.5mA @ 120Hz
Ripple Current @ High Frequency	2.4mA @ 10kHz
Lead Spacing	0.098" (2.50mm)
Size / Dimension	0.248" Dia (6.30mm)
Height - Seated (Max)	0.492" (12.50mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can

UVY1A332MHD1TO	Nichicon, 3300µF 10V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVY	View
UVY2C101MHD1TO	Nichicon, 100µF 160V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVY	View
UVY2A102MHD	Nichicon, 1000µF 100V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVY	View
UVY0J102MPD	Nichicon, 1000µF 6.3V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVY	View
UVY2D0R1MED1TD	Nichicon, 0.1µF 200V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVY	View
UVY2W100MPD1TD	Nichicon, 10µF 450V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVY	View
UVY2V4R7MPD1TD	Nichicon, 4.7µF 350V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVY	View
UVY2G3R3MPD1TD	Nichicon, 3.3µF 400V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVY	View
UVY1H103MRD	Nichicon, 10000µF 50V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVY	View
UVY1J220MDD1TD	Nichicon, 22µF 63V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVY	View
UVY1A682MHD1TN	Nichicon, 6800µF 10V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVY	View
UVY2G010MED1TD	Nichicon, 1µF 400V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, UVY	View

UVY2D0R1MED1TD

Part NumberUVY2D0R1MED1TD
