UUG1J101MNQ1ZD


UUG1J101MNQ1ZD

Part NumberUUG1J101MNQ1ZD

Manufacturer

Description

Datasheet

Package / CaseRadial, Can - SMD

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description

UUG1J101MNQ1ZD - Product Attributes

Categories Capacitors / Aluminum Electrolytic Capacitors
Datasheet
Standard Package70
ManufacturerNichicon
SeriesUUG
PackagingTray
Part StatusActive
Capacitance100µF
Tolerance±20%
Voltage - Rated63V
ESR (Equivalent Series Resistance)-
Lifetime @ Temp.2000 Hrs @ 85°C
Operating Temperature-40°C ~ 85°C
PolarizationPolar
Ratings-
ApplicationsGeneral Purpose
Ripple Current @ Low Frequency370mA @ 120Hz
Ripple Current @ High Frequency555mA @ 10kHz
Lead Spacing-
Size / Dimension0.492" Dia (12.50mm)
Height - Seated (Max)0.571" (14.50mm)
Surface Mount Land Size0.535" L x 0.535" W (13.60mm x 13.60mm)
Mounting TypeSurface Mount
Package / CaseRadial, Can - SMD
