Categories	Capacitors / Aluminum Electrolytic Capacitors
Datasheet	UPV Series
Standard Package	1
Manufacturer	Nichicon
Series	UPV
Packaging	Cut Tape (CT)
Part Status	Active
Capacitance	68µF
Tolerance	±20%
Voltage - Rated	35V
ESR (Equivalent Series Resistance)	-
Lifetime @ Temp.	5000 Hrs @ 105°C
Operating Temperature	-55°C ~ 105°C
Polarization	-
Ratings	-
Applications	General Purpose
Impedance	410 mOhms
Lead Spacing	0.138" (3.50mm)
Size / Dimension	0.315" Dia (8.00mm)
Height - Seated (Max)	0.512" (13.00mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can

UPV1V220MFD1TD	Nichicon, 22µF 35V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UPV	View
UPV1V270MFD1TD	Nichicon, 27µF 35V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UPV	View
UPV1H6R8MFD1TD	Nichicon, 6.8µF 50V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UPV	View
UPV1C151MGD1TD	Nichicon, 150µF 16V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UPV	View
UPV1A101MGD1TD	Nichicon, 100µF 10V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UPV	View
UPV1H470MGD1TD	Nichicon, 47µF 50V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UPV	View
UPV1V560MGD1TD	Nichicon, 56µF 35V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UPV	View
UPV1H4R7MFD1TD	Nichicon, 4.7µF 50V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UPV	View
UPV1E390MFD1TD	Nichicon, 39µF 25V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UPV	View
UPV1V330MGD1TD	Nichicon, 33µF 35V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UPV	View
UPV1H180MFD1TD	Nichicon, 18µF 50V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UPV	View
UPV0J151MGD1TD	Nichicon, 150µF 6.3V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, UPV	View

UPV1V680MGD1TD

Part NumberUPV1V680MGD1TD
