UPJ2A561MHD

Part NumberUPJ2A561MHD

ManufacturerNichicon

DescriptionCAP ALUM 560UF 20% 100V RADIAL

DatasheetUPJ Series

Package / CaseRadial, Can

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed Description560µF 100V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C

To learn about the specification of UPJ2A561MHD, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add UPJ2A561MHD with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of UPJ2A561MHD.
We are offering UPJ2A561MHD for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

UPJ2A561MHD - Product Attributes

Categories

Capacitors / Aluminum Electrolytic Capacitors

Datasheet

UPJ Series

Standard Package

Manufacturer

Nichicon

Series

UPJ

Packaging

Bulk

Part Status

Active

Capacitance

560µF

Tolerance

±20%

Voltage - Rated

100V

ESR (Equivalent Series Resistance)

Lifetime @ Temp.

5000 Hrs @ 105°C

Operating Temperature

-55°C ~ 105°C

Polarization

Polar

Ratings

Applications

General Purpose

Ripple Current @ Low Frequency

1.68A @ 120Hz

Ripple Current @ High Frequency

2.07A @ 10kHz

Impedance

41 mOhms

Lead Spacing

0.295" (7.50mm)

Size / Dimension

0.709" Dia (18.00mm)

Height - Seated (Max)

1.398" (35.50mm)

Surface Mount Land Size

Mounting Type

Through Hole

Package / Case

Radial, Can
