Categories	Capacitors / Aluminum Electrolytic Capacitors
Datasheet	UMW Series
Standard Package	2000
Manufacturer	Nichicon
Series	UMW
Packaging	Tape & Box (TB)
Part Status	Active
Capacitance	4.7µF
Tolerance	±20%
Voltage - Rated	25V
ESR (Equivalent Series Resistance)	-
Lifetime @ Temp.	1000 Hrs @ 85°C
Operating Temperature	-40°C ~ 85°C
Polarization	Polar
Ratings	-
Applications	Audio
Ripple Current @ Low Frequency	16mA @ 120Hz
Ripple Current @ High Frequency	24mA @ 10kHz
Lead Spacing	0.059" (1.50mm)
Size / Dimension	0.157" Dia (4.00mm)
Height - Seated (Max)	0.236" (6.00mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can

UMW1V470MDD1TP	Nichicon, 47µF 35V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 85°C, UMW	View
UMW1C100MDD1TP	Nichicon, 10µF 16V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 85°C, UMW	View
UMW1A220MDD1TP	Nichicon, 22µF 10V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 85°C, UMW	View
UMW1E101MDD1TP	Nichicon, 100µF 25V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 85°C, UMW	View
UMW0G101MDD1TP	Nichicon, 100µF 4V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 85°C, UMW	View
UMW1A101MDD1TP	Nichicon, 100µF 10V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 85°C, UMW	View
UMW0J221MDD1TP	Nichicon, 220µF 6.3V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 85°C, UMW	View
UMW1E100MDD1TP	Nichicon, 10µF 25V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 85°C, UMW	View
UMW1E220MDD	Nichicon, 22µF 25V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 85°C, UMW	View
UMW1E470MDD1TP	Nichicon, 47µF 25V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 85°C, UMW	View
UMW1E220MDD1TP	Nichicon, 22µF 25V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 85°C, UMW	View
UMW0J221MDD1TP	Nichicon, 220µF 6.3V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 85°C, UMW	View

UMW1E4R7MDD1TP

Part NumberUMW1E4R7MDD1TP
